Chapter 3: Set-Up & Programming
Installation & Programming Manual 12
Command 5: Move Timeout Data
This command programs the move detect timeout and the no move detect timeout. The
parameters for this command are defined below:
Parameter 1 is the LDT input number. The number is either 1 or 2.
Parameter 2 is the timeout for when movement should be detected when the input is activated.
The unit of measurement is to the 0.01s. The default value is 1 second (100). A time of zero will
disable this check.
Parameter 3 is the timeout for when no movement should be detected when the input is
deactivated. The unit of measurement is to the 0.01s and the default value is 1 second (100). A
time of zero will disable the check for no movement.
Command 6: Save Configuration
This command saves the data to the EEPROM. The parameters for this command are defined
below:
NOTE: The EEPROM on the 1746L is only guaranteed to 10,000 write cycles. Because of this
it is recommended that this command be used sparingly.
Parameters 1 and 2 will contain a code that will be verified by the software before any of the
data is saved to EEPROM. Password 1 is 2222 and Password 2 is 3333.
Input Image Table
The Input Image Table is used to send the system data back to the SLC Processor. There are 8
data words in the Input Image Table. The I/O Image Table will vary depending on the configura-
tion as shown below:
Output Image Table Description
Word 0 Bit Register
Word 1 Command Register (5)
Word 2 Parameter 1 Input Number
Word 3 Parameter 2 Move Timeout
Word 4 Parameter 3 No Move Timeout
Word 5 Parameter 4 Reserved
Word 6 Parameter 5 Reserved
Word 7 Parameter 6 Reserved
Output Image Table Description
Word 0 Bit Register
Word 1 Command Register (6)
Word 2 Parameter 1 Password 1 (2222)
Word 3 Parameter 2 Password 2 (3333)
Word 4 Parameter 3 Reserved
Word 5 Parameter 4 Reserved
Word 6 Parameter 5 Reserved
Word 7 Parameter 6 Reserved
