13
Visualisation of sensor error detection and
input signal outside range
Sensor error check:
Setup Sensor error detection:
R1, ERR.ACT=NONE ­ R2, ERR.ACT=NONE,
OUT.ERR=NONE
OFF
Else: ON
Outside range readout (IN.LO, IN.HI):
If the valid range of the A/D converter or the polynomial is exceeded
Input Range Readout Limit
VOLT
0...1 V / 0.2...1 V
IN.LO < ­25 mV
IN.HI > 1.2 V
0...10 V / 2...10 V
IN.LO < ­25 mV
IN.HI > 12 V
CURR 0...20 mA / 4...20 mA
IN.LO < ­1.05 mA
IN.HI > 25.05 mA
LIN.R
0...800 Ω
IN.LO < 0 Ω
IN.HI > 1075 Ω
0...10 k Ω
IN.LO < 0 Ω
IN.HI < 110 k Ω
POTM ­
IN.LO < ­0.5 %
IN.HI > 100.5 %
TEMP TC / RTD
IN.LO < temperature range ­2°C
IN.HI > temperature range +2°C
