RocketRAID 2210 Driver and Software Installation
move the disk to the right side of the interface (selected disks). Disks must be
selected one a time.
If you wish to remove a selected disk, highlight it from the selected disk section,
and use the button to move it to the available disk section.
Note: The selection sequence is important - the order in which the disks are
selected will determine the disk sequence of the array.
7. Select the capacity - the RocketRAID 2210 can create arrays between partitions
on various disks. It is not limited to physical hard disk drives. As a result of this
feature, you have the option of assigning a physical disk to multiple RAID
arrays.
Press ENTER to use the default value (the maximum capacity for the array), or
specify the desired value using the keyboard, and press ENTER to confirm this
selection. Then, click the Finish button.
Note: If you have specified an initialization option, the initialization process will start
automatically. A progress bar will be displayed towards the bottom of the interface
window, and will indicate % completion, and provide an estimate of the time needed
to complete the initialization procedure.
4 - Deleting an Array
To delete an array:
1. Highlight the “Management” menu, then select the “Array Management”
function.
2. Highlight the array you want to delete, then click on the “Delete Icon” or select
the Delete command from the “Operation” menu.
3. A warning message will appear. Click Yes to delete the array. Click on cancel to
stop this procedure.
Note: An array in use by the operating system cannot be deleted. Any data stored on
a deleted array will be inaccessible.
5 - Configuring Spare Disks
Spare disks can be used to rebuild redundant RAID arrays in the case of failure.
To configure spare disks, highlight the “Management” menu, and select the “Spare
4-8
