Step 3: Attach LUN to VD.
There are 2 methods to attach LUN to VD.
1. In “/ Volume configuration / Virtual disk”, move the mouse pointer to
the gray button next to the VD number; click “Attach LUN”.
2. In “/ Volume configuration / Logical unit”, click
“ ”.
The procedures are as follows:
1. Select a VD.
2. Input “Host” name, which is a FC node name for access control, or fill-in
wildcard “*”, which means every host can access to this volume. Choose
LUN and permission, then click “ ”.
3. Done.
NOTE: The matching rules of access control are from top to
bottom in sequence.
