Sandvik Coromant Threading - Manual (Page 96)

96
CMC 02.1
MC P2.1.Z.AN
0.50 0.75 1.00 1.25 1.50 1.75 2.00 2.50 3.00 3.50 4.00 4.50 5.00 5.50 6.00
1 0.10 0.16 0.16 0.17 0.20 0.17 0.20 0.20 0.20 0.24 0.24 0.27 0.29 0.27 0.30
.004 .006 .006 .007 .008 .007 .008 .008 .008 .009 .009 .011 .011 .011 .012
2 0.09 0.15 0.15 0.15 0.19 0.17 0.19 0.19 0.19 0.23 0.22 0.25 0.28 0.26 0.29
.004 .006 .006 .006 .007 .007 .007 .007 .007 .009 .009 .010 .011 .010 .011
3 0.08 0.12 0.14 0.14 0.18 0.16 0.18 0.18 0.19 0.22 0.22 0.24 0.27 0.26 0.29
.003 .005 .006 .006 .007 .006 .007 .007 .007 .009 .009 .009 .011 .010 .260
4 0.07 0.07 0.12 0.13 0.16 0.15 0.17 0.17 0.18 0.21 0.21 0.23 0.26 0.25 0.28
.003 .003 .005 .005 .006 .006 .007 .007 .007 .008 .008 .009 .010 .010 .011
5 0.08 0.12 0.14 0.14 0.16 0.17 0.17 0.21 0.21 0.23 0.25 0.25 0.27
.003 .005 .006 .006 .006 .007 .007 .008 .008 .009 .010 .010 .011
6 0.08 0.08 0.13 0.15 0.16 0.17 0.20 0.20 0.22 0.25 0.24 0.26
.003 .003 .005 .006 .006 .160 .008 .008 .009 .010 .009 .010
7 0.11 0.13 0.15 0.16 0.18 0.19 0.21 0.24 0.23 0.26
.004 .005 .006 .006 .007 .007 .008 .009 .009 .010
8 0.08 0.08 0.14 0.15 0.17 0.18 0.20 0.23 0.23 0.25
.003 .003 .006 .006 .007 .007 .008 .009 .009 .010
9 0.12 0.14 0.16 0.17 0.19 0.22 0.22 0.24
.005 .006 .006 .007 .007 .009 .009 .009
10 0.08 0.13 0.15 0.16 0.18 0.20 0.21 0.23
.003 .005 .006 .006 .007 .008 .008 .009
11 0.12 0.13 0.15 0.17 0.19 0.20 0.22
.005 .005 .006 .007 .007 .008 .009
12 0.08 0.08 0.14 0.16 0.17 0.19 0.20
.003 .003 .006 .006 .007 .007 .008
13 0.12 0.14 0.15 0.18 0.19
.005 .006 .006 .007 .007
14 0.08 0.10 0.10 0.16 0.17
.003 .004 .004 .006 .007
15 0.14 0.15
.006 .006
16 0.10 0.10
.004 .004
0.34 0.50 0.65 0.79 0.95 1.11 1.26 1.56 1.88 2.18 2.49 2.79 3.10 3.39 3.70
.013 .020 .026 .031 .037 .044 .050 .061 .227 .086 .098 .110 .122 .133 .146
5. Technical reference
Thread turning infeed recommendations
ISO Metric (MM), external
Pitch, mm
No. of
infeeds
Unit Radial infeed per pass
mm
inch
mm
inch
mm
inch
mm
inch
mm
inch
mm
inch
mm
inch
mm
inch
mm
inch
mm
inch
mm
inch
mm
inch
mm
inch
mm
inch
mm
inch
mm
inch
Total infeed
mm
inch
Extra stock is included in the total infeed 0.05 mm
.002 inch
Reference material
