Sandvik Coromant Threading - Manual (Page 59)

59
VM MM – UN
 
GC1025
(VM, MM-UN)
CB7015 (VM)
WH – NT AC – SA
 
GC1025
3. Products - thread turning
V-profi le 60° (VM)
Pitch: 0.5 – 1.5 mm
48 – 16 t.p.i. Metric: 60° (MM)
Pitch: 0.5 – 2.0 mm
UN 60° (UN)
Pitch: 32 – 16 t.p.i.
Type of insert
F-sharp
 
Geometry F-sharp
Grade ISO
Whitworth 55°
Pitch: 28 – 19 t.p.i. ACME 29° (AC)
Pitch: 1.5 – 3 mm
NPT 60° (NT)
Pitch: 27 – 18 t.p.i. STUB-ACME 29° (SA)
Pitch: 16 – 8 t.p.i.
Type of insert
F-sharp
Geometry F-sharp
Grade ISO
Assortment - CoroTurn® XS
