background image

Product Number: 6311VP2

Davis Instruments Part Number: 07395.314

Vantage Pro2 Updater Manual
Rev. A Manual (12/17/04)

This product complies with the essential protection requirements of the EC EMC Directve 89/336.

3465 Diablo Avenue, Hayward, CA 94545-2778

510-732-9229 • Fax: 510-732-9188

E-mail: [email protected] • www.davisnet.com

A PC is required to install new versions of firmware on the Updater. The installation
is done through a serial port at 19,200 baud using the Updater software provided by
Davis.

Using Updater Software to Update the Firmware on the Updater

1. Make sure the flash.bin file is in the Updater software directory before you start

the program.

2. Connect the included serial cable to the Updater’s serial port (see Fig. 2). The

other end of the cable connects to the serial port on your computer using the
included serial port adapter.

3. Turn the VP Updater ON using the ON switch (see Figure 2).

4. Start the Updater software.

5. The software should detect the Updater on one of your serial ports.

Note:

If the Updater Software doesn’t detect the Updater, check all the connections and make sure bat-
tery is good or check that the AC-power adapter is connected and receiving power.

6. When the software asks, "

LOAD NEW FIRMWARE TO UPDATER? (Y or N)

":

Press “Y” to update the firmware in the Updater.

You can press “N” to cancel the operation.

7. The program will load the new firmware into the Updater and double check that

the firmware loaded correctly.

8. Type 'Q' to quit the program. You can then close the window.

Contacting Davis Instruments

(510) 732-7814 Technical Support, Monday – Friday, 7:00 a.m. – 5:30 p.m. Pacific Time.
(510) 670-0589 Fax to Customer Service or Tech Support.
www.davisnet.com Davis Instruments’ website. Check out the Weather Support section.
[email protected] E-mail to Technical Support.
