DAVIS Wireless Temperature Station Installation Addendum - Manual

Product # 6370
A d d e n d u m To :
W i r e l e s s Te m p e r a t u r e Sta t i o n
I n s ta l l a t i o n M a n u a l
Changes Covered In This Addendum
• The temperature sensor is now shipped separately and must be con-
nected to the Wireless Temperature Station during the installation.
• This station requires a few additional steps when you are setting the con-
sole/receiver(s) transmitter ID.
Temperature Sensor Connections
Please refer to the following instructions when you are preparing the Wireless
Temperature Station for installation. Please perform these steps just before you
install the 3-volt lithium battery, Page 3 in the Wireless Temperature Station
Installation Manual.
1. Open the station housing.
2. Take square rubber grommet from the right side on the bottom of the sta-
tion housing
3. Run the temperature sensor cable through it.
When you reinstall the grommet, be sure the connector end of the sensor
cable is located on the inside of the housing. You’ll need at least
4. Install the grommet back into the slot in the station housing with the sen-
sor cable connector , adjusting the inside cable length as needed for a
tidy installation.
5. Refer to the illustration and connect the temperature sensor cable to the
modular connector labeled TEMP/HUM.
6. Use the small, 4 inch (100 mm) cable tie provided with your station to
secure the sensor cable to the cable tie mount.
The cable tie will provide strain relief for the sensor cable connection.
7. Continue with the installation as described in the Wireless Temperature
Station Installation Manual, starting with Setting the Transmitter ID on
page 4.
