Installing the Rain Collector Heater
9
11.Secure the cable to the heater
assembly by running a cable
tie over the cable and through
the hole as shown. You can
cut off excess cable tie.
12.To provide strain relief for
the cable, place a cable tie
around the cable just above
the hole through which this
cable is running, as shown
below.
You may want to cut off the
excess cable tie.
13.Re-attach (or attach) the rain
collector to the mounting
surface.
Installing the Insulation Blanket
1. Fit the insulation blanket against
the side of the rain collector
cone, pushing it as far inside the
cone as it will go.
If fully inserted correctly, the
blanket should extend all the
way to the top of the cone,
leaving a space of approximately
5/16” (8 mm) at the bottom to
accommodate the base.
2. Re-attach the rain collector cone
(with insulation blanket) to the
base.
Cable Tie
Securing cable to heater
Providing Strain Relief
Inserting the insulation
