Attaching ground wires – DAVIS Grounding Kit User Manual
Page 4
Product Number: 7780
Davis Instruments Part Number: 7395-083
Grounding Kit
Rev. B Manual (7/7/99)
This product complies with the essential protection requirements of the EC EMC
Directive 89/336/EC.
© Davis Instruments Corp. 1997. All rights reserved.
A
TTACHING
G
ROUND
W
IRES
To attach ground wires to the rod, strip away 1 inch (3 cm) of insulation, insert
the wires between the wire clamp and the rod, and secure the wires in place by
tightening the wire clamp as shown below.
