Checking Settings:
The current setting for the different adjustments can
be verified at any time using the Test button and the
LED. This process is divided into 3 sections.
Standard, Advanced and Null Zone. The different
sections are chosen by the position by the dial when
the verification is started.
The Standard values can be verified at any time by
following these steps.
1. Turn the power “On”
2. Set “Mode” dial any position from 1-7.
3. Press the “Test” button and HOLD
DOWN.
4. The LED will glow solid for 8
seconds (as in the Forced Activation Test),
then blink to show the firmware version.
5. Next the LED will flash the value for the Buffer.
(A setting of zero is indicated by a short blip of
the LED).
6. After a short pause, the Led will flash for the
value of Sample Rate, followed by a pause.
8. Lastly, the LED will Flash the current Self
Learning status value.
(for tech support
purposes only).
