Lokar Automatic Transmission Shifter Ford C4/C6 Tailmount User Manual
Page 4
INS0100 Rev. 07/03/14
Page 4
Fig. 5
Fig. 6
Fig. 7
Fig. 8
The Button Head Bolt can be
installed from either direction,
but make sure the Rod End is
sandwiched between the Flat
Washer and the Quad Lever
The Button Head Bolt can be
installed from either direction,
but make sure the Rod End is
sandwiched between the Flat
Washer and the Trans Arm
1/4"-28 x 1"
Button Head Bolt
Quad Lever
1/4"-28 Nylock Nut
1/4"-28
Jam Nut
Threaded Rod
1/4"-28 Nylock Nut
1/4"-28
Jam Nut
Trans Arm
1/4"-28 x 1"
Button Head Bolt
Rod
End
Flat Washer
Threaded
Rod
Flat
Washer
Rod
End
Measur
e This Distanc
e and Subtr
act 1-3/4"
