ididit Retrofit Steering Column: 1970-74 Cuda/Challenger - Manual (Page 6)

(Figure 11)
Knobs & Levers:
Tilt Lever
After removing all items from the package, screw the knobs onto the levers. The tilt
lever is installed on the left side of the column in the threaded hole located closest to
the dash. We recommend using Locktite.
Emergency Flasher
The Emergency flasher is threaded into the hole located on the right side of the
column. You will noticed the plastic portion that the flasher screws into is flush with
the outer surface when the flashers are in the off position. It is easy to accidently turn
the flashers ON while installing which could lead to problems later. Check to make
sure the flashers are in the OFF position before continuing.
Turn Signal Lever
A screw is provided with the Dress-up kit. This screw with secure the turn signal
lever to the column.
PLEASE NOTE there are two holes on the turn signal switch.
One D shaped and the other is round. The screw is to be inserted in the round hole!
Use a #2 Phillips screw driver to tighten this screw tightly. It holds the lever and the
switch half’s together.
(See Figure 11, 12, 13)
(Figure 12)
(Figure 13)
5
