There are a few aftermarket harnesses out there for this application. Some are a
direct factory replacement. Others are based on the GM wire color code. Our wire
code is GM based. If you get one of these kits we have matching connectors and
this may also plug directly in. Note that our turn signal plug is the 4 ¼ male plug.

If you have an aftermarket wiring harness, please resist the urge to cut the plug’s
off.

We have both male plugs and both female plugs in stock if you need one that was
not supplied with the kit. These plugs come with terminals, and instructions. If this
is the case for your installation please call us at (517) 424-0577.

General Electrical Tips

Hey it’s a big world… and just in case you are using a unusual combination of parts,
here’s the nuts and bolts of the electrical system.

Turn Signal Switch

Black Horn relay trigger, GROUND TO SOUND

Lt. Blue Left front turn signal and indicator

DK Blue Right front turn signal and indicator

Brown 4 way feed wire, Hot from Flasher Can hot all the time.

Purple Turn signal feed. Hot with ignition on only.

Yellow Left rear turn and brake

Green Right rear turn and brake
White Brake feed from brake switch

Ignition Switch

RED Battery power in by way of back of starter.

Brown Goes to accessory side of fuse panel. Die’s out during crank.

Pink Goes out to coil as feed for ignition, through resistor, and stays hot in

run and crank. Also may be used as feed for limited items on fuse panel such as an

electric fuel pump.

Purple Hot out to starter solenoid. This wire interrupted for Neutral Safety.
Black Ground for the relays to trigger.

Aftermarket Wire Harness Tech Note:
