4

Installing the column:

You will be using the original mounts, but you may want to consider

replacing the floor seal. Normally it will be pretty trashed from

removing it the first time.

Protect that new column!!! We recommend that you wrap the lower

4-6 inches of the column with masking tape. Then slip the seal & floor

mount (with tabs facing engine compartment) over the column. Tape

the seal & mount to the column so it doesn’t scratch the column.

A helper would be handy at this time!

You are going to loosely install the column to mark the setscrew

location.

Install the steering column by sliding

it gently through the firewall and into

the coupler. (Figure 2) You may have

to turn the shaft slightly to engage the

spline into the coupler. While your

supporting the column verify that the

column aligns with the tab in the upper

half of the dash mount. The column

should be inserted into the coupler 1

inch.

While holding the column have your helper install the setscrews

into the coupler. Next gently tighten them onto the column & then

loosen and remove the setscrews. Doing this will mark the spot

where you need to drill the shaft! Now remove the column out of the

vehicle and spot drill a dimple into the shaft with the same 5/16 drill

bit approximately 1/8 of an inch deep. This should be just past the

bottom of the spline depth.

You will want to clean and debur this area fully, we recommend using

a small file.

Now have the helper go back outside the fire wall and guide the

column into the coupler. Install the setscrew and jam nut with Locktite.

Make sure the setscrew aligns with the dimple on the column.

(Figure 2)
