1966 Nova

ididit column

Function

Car harness

P-White

Brake Feed

White

N-Green

Right rear, turn and brake

Dark Green

M-Yellow

Left rear, turn and brake

Yellow

L-Purple

Turn signal flasher feed

Purple

K-Brown

4-way flasher Feed

N/A

J-Dark Blue

Right front, turn and indicator

Dark Blue

H-Light Blue

Left front, turn and Indicator

Light Blue

G-Black

Horn (ground)

Black

Aftermarket Harness:

If you have an aftermarket harness use the mate provided in the

kit. Our column has the 3 7/8 inch male GM plug.

OEM wiring w/out Flasher Kit:

If you have the OEM harness and chose

not to get the flasher kit… we have a

female connector kit PN# 3106050010.

(Figure 9) This kit includes all the

terminals and the matching connector

to the column.

Knobs & Levers:

Tilt Lever:

After removing all items from the package,

screw the knobs onto the levers. The tilt lever

is installed on the left side of the column in

the threaded hole located closest to the dash.

We recommend using Locktite. (Figure 10)

8

(Figure 9)

(Figure 10)
