ididit Retrofit Steering Column: Tri-Five Chevy - Manual (Page 3)

2
The Classic Chevy Floor Mount is made up of two pieces:
A.) T-shaped L Bracket
B.) Clamp
The T shaped bracket mounts in the original bolt holes in the inside floor
of your Chevy. The long extension
comes forward toward the driver.
The clamp should slide up the tube
of the steering column. The steer-
ing column then slides above the
extension and through the floor
board. The clamp will slide over
the extension of the floor bracket
and around the column. Your col-
umn is now secured to the floor to prevent any movement. Tighten all
fasteners when you are comfortable with the installation.
B.
A.
