Boonton 4240 Series RF Power Meter
Figure 3-15. Access Code
R T N
M > 5 1 0 7 O D E L 5
S # 2 9 3 9 E R I A L 1
D 0 8 2 A T E 3 1 0
U 0 : 5 0 P S C A L E 0 0
D O W 0 N S C A L E 0 : 0 0 0
F R E Q C . F .
M A X F R E Q 1 8 . 0 0
M I N F R E Q 0 . 0 0
M A X P O W E R 2 3 . 0 0
M I N P O W E R - 7 5 . 0 0
Figure 3-16. Sensor Edit Data Menu Display
The parameter list will show TBLn (where n = 1, 2, 3, 4) when a serial number has not been entered for the corresponding
internal table. For example, TBL3 will be displayed if the serial number has not been previously entered for internal table 3. In
addition, the parameter list will show ADPTn (where n = 1, 2) if a serial number has not been entered for the table contained
within the sensor data adapter. For example, ADPT2 is displayed when the serial number has not been previously entered for
sensor data adapter 2.
To edit the sensor calibration data, move the cursor to the EDIT DATA function and press . Scroll through the power
sensor serial numbers until the desired selection is displayed. Press to proceed. Enter the access code to edit or
depress the
Table 3-8 Sensor Edit Data Menu Functions
Function Description
Parameters Defaults
RTN
Returns the instrument to the n/a n/a
MODEL
Power sensor model number 0 to 99999 0
SER #
Power sensor serial number 0 to 99999 0
Table 3-8 Sensor Edit Data Menu Functions
(continued)
The access code to enter the Edit Data menu is as follows:
Press the front panel switches in the following order:
Getting Started
3-16
