VSC operations 85
Viewing VSC configuration information
The Refer Configuration function allows you to view the VSC information
for the connected disk array. This function can be used to view the disk
array configuration information before making changes and to verify
changes. When you select Refer Configuration, all VSC functions will be
disabled, and you will not be able to request any configuration changes.
Using Refer Configuration, you can view the following information:
• parity group configuration of each CU, including the number of
LUNs, emulation type, and RAID level of each parity group. This
information is displayed on the Device Emulation Configuration
window.
• device configuration of each parity group, including the LUN ID,
emulation type, and current VSC configuration of each LUN in the
parity group. This information is displayed on the Device Emulation
Detail window.
• CV configuration of each VSC volume, including the capacity (user
and total) and emulation type of each CV. This information is
displayed on the Volume Size Configuration Define window.
• LUN ID configuration for each parity group, including LUN IDs
assigned to normal volumes and CVs. This information is displayed on
the Logical Device ID Configuration and Logical Device ID Define
windows.
• storage subsystem ID (SSID) configuration within each CU. This
information is displayed on the Subsystem ID Configuration window.
