HP ProLiant DL380e Gen8 Server - Manual (Page 25)

Operations 25
1. Install the air baffle.
2. Install the access panel (on page 24 ).
3. Install the server into the rack (" Installing the server into the rack " on page 33 ).
4. Power up the server (on page 20 ).
Remove the PCI riser cages
CAUTION: To prevent damage to the server or expansion boards, power down the server, and
disconnect all power cords before removing or installing the PCI riser cage.
1. Power down the server (on page 20 ).
2. Remove all power:
a. Disconnect each power cord from the power source.
b. Disconnect each power cord from the server.
3. Do one of the following:
o Extend the server from the rack (on page 20 ).
o Remove the server from the rack (on page 22 ).
4. Remove the access panel (on page 23 ).
5. Disconnect all cables connected to the expansion board.
6. Lift the release tabs, and then rotate them 180° counterclockwise.
7. Lift the PCI riser cage to unseat the PCI riser boards.
