HP ProLiant DL380e Gen8 Server - Manual (Page 13)

Component identification 13
Slot
number Riser board option Type Length Height Connector
link width
Negotiable
link width
6 PCIe x16 riser board* PCIe3 Half Full x16 x8
* Ships with the secondary PCI riser cage option
System board components
Item Description
1 PCI riser connectors*
2 Cache module connector
3
TPM connector
4 Mini-SAS connector
5 SATA drive connector
6 System battery
7 SATA optical/storage drive connector
8 Front panel connectors
9 Primary GPU power connector
10 Reserved
11
Fan connector 6
12 Fan connector 5
13 Fan connector 4
14
Reserved
15 Internal USB connector
