Specifications 121
• HP 750 W CS Platinum Plus Hot-plug Power Supply (94% efficiency) (on page 123 )
• HP 750 W CS Titanium Hot-plug Power Supply (96% efficiency) (on page 123 )
• HP 750 W CS -48 V DC Hot-plug Power Supply (94% efficiency) (on page 124 )
• HP 1200 W CS Platinum Plus Hot-plug Power Supply (94% efficiency) (on page 125 )
For detailed power supply specifications, see the QuickSpecs on the HP website
(
http://h18000.www1.hp.com/products/quickspecs/14209_div/14209_div.html ).
CAUTION: Check the system and power supply input ratings before powering up the server.
HP 460 W CS Gold Hot-plug Power Supply (92% efficiency)
Specification Value
Input requirements —
Rated input voltage
100 V AC to 240 V AC
Rated input frequency 50 Hz to 60 Hz
Rated input current 6 A to 3 A
Rated input power
526 W at 100 V AC input
505 W at 200 V AC input
Btu per hour 1794 at 100 V AC input
1725 at 200 V AC input
Power supply output —
Rated steady-state power 460 W at 100 V to 120 V AC
input
460 W at 200 V to 240 V AC
input
Maximum peak power 460 W at 100 V to 120 V AC
input
460 W at 200 V to 240 V AC
input
HP 460 W CS Platinum Hot-plug Power Supply (94% efficiency)
Specification Value
Input requirements —
Rated input voltage 100 V AC to 240 V AC
Rated input frequency 50 Hz to 60 Hz
Rated input current 6 A to 3 A AC input
Rated input power 517 W at 100 V AC input
496 W at 200 V AC input
Btu per hour 1764 at 100 V AC input
1736 at 120 V AC input
1694 at 200 V AC input
1692 at 208 V AC input
1689 at 220 V AC input
1687 at 230 V AC input
1686 at 240 V AC input
