A Specifications
Functional specifications
Table A-1 HP Scitex UV pigment ink supplies
Printheads 2 heads per color: Cyan, Magenta, Yellow, Black, Light
Cyan, Light Magenta. White ink option replaces Light Cyan
and Light Magenta with White.
Ink cartridges Cartridges containing 3 liters of ink: Cyan (CH216A),
Magenta (CH217A), Yellow (CH218A), Black (CH219A),
Light Cyan (CH220A), Light Magenta (CH221A).
Cartridges containing 2 liters of ink: White (CQ123A)
Table A-2 Media sizes
Minimum Maximum (FB500) Maximum (FB700)
Media thickness 0.127 mm (0.005 in) 64 mm (2.5 in) 64 mm (2.5 in)
Sheet size with standard
input and output tables Width: 15 cm (6 in) Length: 1.2 m (48 in)
Width: 1.6 m (64 in)
1.2 m (48 in)
2.5 m (98 in)
Sheet size with standard
tables and optional
accessory extension tables Length: 10 cm (4 in)
Width: 15 cm (6 in)
Length: 3 m (120 in)
Width: 1.6 m (64 in)
Length: 3 m (120 in)
2.5 m (98 in)
Maximum sheet-fed media
weight N/A 68 kg (150 lb) 68 kg (150 lb)
Sheet flatness Perfectly flat +/- 0.5 mm (0.02 in) +/- 0.5 mm (0.02 in)
Roll width 15 cm (6 in) 164 cm (64.5 in) 250 cm (98.4 cm)
Roll diameter N/A 23 cm on 7.6 cm core (9 in
diameter on 3 in core) 23 cm on 7.6 cm core (9 in
diameter on 3 in core)
Roll weight N/A 82 kg (180 lb) 82 kg (180 lb)
Table A-3 Functional specifications
Print resolutions RIP supports print modes that include resolutions of
1200x600, 600x600 and 600x300
Minimum Margins Set by the RIP, can be set to 0 (edge-to-edge) on rigid and
roll-fed media
Technology UV curable inkjet
UV energy source Dual shuttered UV lamps
Ink drop Variable size
