14
Existing setup Add the PC with a splitter
Wall
Cable
VCR In
VCR Out
TV In
Splitter In
Splitter Out
TV (in) on
back of PC
Coaxial
cable
Coaxial
cable
Wall
Cable
VCR In
VCR Out
TV In
Coaxial cable
Connecting the TV Signal Source
When You Have an Existing Setup
This section describes how to connect the PC to an
existing setup for your TV signal source.
Wall to VCR to TV using coaxial cable
Remove the coaxial cable at the input to the VCR, and
connect it to the input of a coaxial cable signal splitter
(not included; available at electronics stores). Connect
two coaxial cables to the splitter outputs. Connect one of
these cables to the input of the VCR and the other one to
the TV connector on the back of the PC.
