Chapter 3
3-5
Operating the Jukebox
Operating the Control Panel
Op
eratin
g th
e
Ju
kebo
x
The numbers below refer to the numbers in Figure 3-1 on the previous page.
NOTE
Figure 3-2 shows the jukebox menus available using the control panel selection
buttons.
1
Swivel feature
The control panel assembly may be rotated to face the
display (#3 below) toward the front or right side of the
jukebox. The front has the vertical window, the right
side has the mailslot.
2
Activity light
Lit differently to indicate the following:
•
Steady Green - power is on
•
Flashing Green - an optical drive is being accessed
•
Amber - a fault occurred
3
16-character
display
Displays information about the current operation.
4
Selection
buttons
Pressed to perform the following operations:
CANCEL
cancels the current operation or choice
PREV
scrolls the display choice backward by one
NEXT
scrolls the display choice forward by one
ENTER
selects the displayed choice
5
Power switch
Used to power the jukebox on and off.
6
Mailslot
Used to load and eject optical disks
