Appendix B

B-13

Operating This Jukebox on a SCSI Bus

Default SCSI IDs in the Jukebox When Using Basic SCSI Addressing

and When Using LUN Mode

Op
eration o

n

a

SC
SI

Bu

s

Table B-2

LUN Mapping if “DRVs” SCSI ID is Changed to an ID Different Than the
Jukebox (IDs used here are an example)

* 320ex models only

LUN Mode ON

ID

LUN

JKBX ID

5

0

DRV 1 ID

6

0

DRV 2 ID

6

1

DRV 3 ID*

6*

2*

DRV 4 ID*

6*

3*
