Chapter 1 1-7
Setting Up the Jukebox
Identifying Controls and Features
Ch
ap
ter
1
: Setti
ng
up
the Disk Driv
e
S
ettin
g u
p
th
e
Ju
kebo
x
5 Active bus
indicator Lit when the SCSI bus is active. There is an indicator
for the single-ended interface and an indicator for the
differential interface
6 SCSI interface
selection switch Used to select either the single-ended or differential
SCSI interface.
7 SCSI ports Used for attaching the SCSI cable from the jukebox to
the host computer. Select either the single-ended or the
differential pair of connectors (see item 5 in this list).
Both ports of a selected interface must be used. One
port must have a SCSI cable connected, and the other
must have either a SCSI terminator connected to it, or
it can be used to daisy-chain to another SCSI device.
8 Power
receptacle Connection for the power cord.
9 Left access
panel Covers the interface assembly (see components 5, 6, 7,
and 8 above). This panel is removed by pushing up on
the panel (from the bottom) and then pulling the panel
out and away.
