126

user’s guide

removing an add-in card

1 Remove the side panel that has thumbscrews. See page 105.
2 Gently lay the PC on its side.
3 To prepare an empty card slot for a new card, loosen the screw of the

expansion slot cover. Remove the cover of the empty slot.

4 If you are replacing a card, make a note of any external or internal cables

attached to the card, and then disconnect them.

5 Loosen the screw on the bracket of the card you are replacing.

6 Hold the bracket and the far top corner of the card. Carefully remove the card

by pulling the card straight out of the expansion slot.

WARNING: Be careful of the sharp edges on the expansion slot
cover.
