Description Type Item
RAID-1 parity group in HDD class C. A similar HDD class C icon
indicating RAID-5 or RAID-6 might also appear. icon
RAID-1 parity group in HDD class D. A similar HDD class D icon
indicating RAID-5 or RAID-6 might also appear. icon
The parity group ID appears directly to the right of the parity group
icon in the following convention: 1-4. If two or more parity groups field Parity group identifier
are connected together, you will see the following convention:
1-3[1-4].
The external volume group ID appears directly to the right of the
external volume group icon in the following convention: E1-2 field External volume group identifier
The Thin Provisioning group ID appears directly to the right of the
Thin Provisioning group icon in the following convention: X16-1 field Thin Provisioning group identifier
HDD Class list
When you select a class in the navigation tree, the HDD Class list displays information about parity
groups in that HDD class. This information is summarized in the following table.
Description Type Item
Indicates the parity group ID. The number before the hyphen is the frame number and the
number after the hyphen is the group number. This list uses the same icons used in the field PG
“Attribute navigation tree” (page 62) . If the indicated parity groups are the interleaved parity
groups, this item only displays the ID of the parity group at the top of the interleaved parity
groups.
Indicates the type of hard disk drive. field HDD
Indicates the average usage rate for the parity group. An exclamation mark (!) preceding
the percentage value indicates that the reported usage rate is likely to be inaccurate. This field Ave. (%)
can occur when volumes used in Auto LUN are also formatted by Virtual LVI or Open Volume
Management. A "+0" succeeding the percentage value indicates that the usage rate is
between 0 and 1 percent.
Indicates the maximum usage rate for the parity group. An exclamation mark (!) preceding
the percentage value indicates that the reported usage rate is likely to be inaccurate. This field Max (%)
can occur when volumes used in Auto LUN are also formatted by Virtual LVI or Open Volume
Management. A "+0" succeeding the percentage value indicates that the usage rate is
between 0 and 1 percent.
Indicates the total number of volumes in the parity group. field Total
Indicates the number of reserved volumes. field Reserved
Indicates the number and name of the CLPR corresponding to the parity group. The following
convention is used: field CLPR
CLPR-number:CLPR-name
Attribute window 63
