Chapter 3 3-3
Operating the Disk Drive
Identifying Front Panel Features
O
p
er
atin
g
th
e
Dis
k
Driv
e
Identifying Front Panel Features
The following list of features corresponds to the numbers in Figure 3-1:
1 Disk slot The opening for inserting/retrieving optical disks
2 Activity indicator Lit when the drive is accessed and while the drive
is loading or ejecting a disk.
3 Power indicator Remains lit while the power is on
4 Eject tool opening An access hole for the eject tool. In an emergency,
such as a power outage, the disk can be manually
ejected by inserting the eject tool into this
opening. See “Manually Ejecting Disks” on the
next page.
5 Eject button Pressed to eject the disk from the drive. The drive
power must be ON.
