Chapter 1 1-5
Setting up the Disk Drive
Rear Panel Features
Ch
ap
ter
1
: Setti
n
g
u
p
th
e Disk
Driv
e
Sett
in
g
u
p
th
e
Di
sk
Dr
iv
e
The following numbers correspond to the numbers in the drawing on the previous
page.
1 SCSI ID switch Used to set the SCSI ID. Refer to “Setting
the SCSI ID” in this section.
2 Operation mode switch Used to choose the operating mode and set
your preference for write verify. Refer to
“Setting the Operation Mode” in this
section.
3 Power connector Receptacle for the power cord.
4 On/Off switch Used to switch power on or off.
5 SCSI connector (with
terminator attached) 50-pin high-density SCSI connector
(Micro D-type). Terminator may be
attached to either connector (see “6”).
A terminator must be plugged into either
“5” or “6” when the drive is the last
physical device on a SCSI bus.
6 SCSI connector (with
cable attached) 50-pin high-density SCSI connector
(Micro D-type). Cable may be attached to
either connector (see “5”).
A terminator must be plugged into either
“5” or “6” when the drive is the last
physical device on a SCSI bus.
