C-2 Compaq Console Management Controller User Guide
Compaq Confidential – Need to Know Required
Writer: A. J. Scheckelhoff Project: Compaq Console Management Controller User Guide Comments:
Part Number: 218258-002 File Name: i-appc Specifications.doc Last Saved On: 6/20/01 7:39 PM
Specifications
Table C-1
Specifications – Console Management Controller (CMC)
Feature Specification
U.S. Metric
Dimensions Height 1.75 in (1U) 44.5 mm
Depth 4.13 in 105 mm
Width 19 in 483 mm
Operating
temperature +10 °C to +50°C
Storage
temperature -20 °C to +60°C
Processor AM186 based (20 MHz), 16-bit CPU, Intel-compatible
RAM 512KB 16-bit DRAM
Program memory 512KB flash-EPROM
CMC Rated
voltage 100 VAC to 240 VAC, 50/60 Hz
CMC Maximum
input current
rating 300mA
Voltage drop time 10 ms (maximum)
Rated voltage for
fan inlet/outlets 100 VAC to 240 VAC, 50/60 Hz
Fan inlet - 4A Maximum current
rating for fans
Fan outlet - 2A (each)
continued
