2-20 Compaq Console Management Controller User Guide
Compaq Confidential – Need to Know Required
Writer: A. J. Scheckelhoff Project: Compaq Console Management Controller User Guide Comments:
Part Number: 218258-002 File Name: c-ch2 Installation.doc Last Saved On: 7/19/01 10:30 PM
Connecting the Input Power Cord to the CMC
Make sure the Power button
is in the Off position before connecting the
input power cord to the rear of the unit.
10
Figure 2-17. Power Button
Connect the input power cord to the input power socket
.
1
Figure 2-18. Input power connection
