1-8 Compaq Console Management Controller User Guide
Compaq Confidential – Need to Know Required
Writer: A. J. Scheckelhoff Project: Compaq Console Management Controller User Guide Comments:
Part Number: 218258-002 File Name: b-ch1 Overview.doc Last Saved On: 7/13/01 2:29 PM
Table 1-3
CMC Rear Panel
Description Type of connector
Main power input AC input (IEC 320-10A)
Input voltage monitor / Power
input for Fan #1 and #2 AC input (IEC 320-10A)
Fan #1 Power output for fan #1 (IEC 320–10A)
Fan #2 Power output for fan #2 (IEC 320–10A)
Relay #1 Alarm relay (RJ-12)
Relay #2 Alarm relay (RJ-12)
Intrusion sensor #1 Discrete input (RJ-12)
Intrusion sensor #2 Discrete input (RJ-12)
Intrusion sensor #3 Discrete input (RJ-12)
Intrusion sensor #4 Discrete input (RJ-12)
Smoke sensor Discrete input (RJ-12)
Shock/vibration sensor Discrete input (RJ-12)
Lock #1 Discrete output (RJ-12)
Lock #2 Discrete output (RJ-12)
Auxiliary 1 Discrete input (RJ-12)
Auxiliary 2 Discrete input (RJ-12)
Temperature sensor #1 Analog input (RJ-12)
Temperature sensor #2 Analog input (RJ-12)
Humidity sensor Analog input (RJ-12)
I 2 C port I 2 C communications (RJ-45)
Ethernet port 10BaseT (RJ-45)
