HP ProLiant DL160 G5 Storage-Server - Manual (Page 41)

Status Description Item
Green = Normal (system on)
Flashing amber = System health degraded
Flashing red = System health critical
Off = Normal (system off)
System Health LED 3
Green = Network link
Flashing = Network link and activity
Off= No network connection
NIC 1 activity LED 4
Green = Network link
Flashing = Network link and activity
Off= No network connection
NIC 2 activity LED 5
N/A Power button 6
N/A
Thumbscrews for rack
mounting
7
See “ SAS and SATA hard drive LED combinations ” on page 49 for HDD
LED status descriptions.
Fault/UID LED 8
See “ SAS and SATA hard drive LED combinations ” on page 49 for HDD
LED status descriptions.
Online LED 9
N/A
Hard disk drive (HDD)
bay
10
Figure 9 DL185 G5 rear panel
Table 12 DL185 G5 rear panel components
Status / Description Description Item
N/A Power supply cable sockets 1
HP ProLiant Storage Server 41
