Media type Maximum amount
that can be loaded
into tray 2 or optional
tray 3 Printer-driver setting Tray 1 media
orientation Tray 2 or tray 3 media
orientation
short edge toward the
product
Labels Zero. Labels should be
used only in tray 1 Labels Side to be printed
facing up, with top edge
to the front of the
product Do not print labels from
tray 2, optional tray 3,
or the ADF.
Transparencies Zero. Transparencies
should be used only in
tray 1 Transparencies Side to be printed
facing up Do not print
transparencies from
tray 2 or optional tray 3.
Letterhead (single-
sided printing) Up to 500 sheets Letterhead Side to be printed
facing up, top edge
toward the product Side to be printed
facing down, top edge
at the front of the tray
Letterhead (2-sided
printing) Up to 500 sheets Letterhead Side to be printed
facing down, top edge
away from the product Side to be printed
facing up, top edge at
the back of the tray
Cardstock Zero. Card stock
should be used only in
tray 1 Cardstock or heavy Side to be printed
facing up Do not print cardstock
from tray 2 or optional
tray 3.
Rough Up to 50 mm (1.97 in)
stack height Rough Side to be printed
facing up Side to be printed
facing down
