Cisco MDS 9124e Fabric Switch for HP c-Class BladeSystem
19
1.
Locate the appropriate interconnect bay in the rear of the enclosure per the HP BladeSystem
c7000 Enclosure setup and installation guide provided with your enclosure.
2.
Remove the slot cover, if installed.
IMPORTANT:
Populate all enclosure I/O bays with the appropriate component; for example a switch, Pass-Thru, or
one of the blank panels provided with the enclosure.
CAUTION:
Properly ground yourself before handling the switch.
3.
Press the handle latch to release the installation handle. See
and
.
Figure 4
Releasing the installation handle
4.
Align the Cisco MDS 9124e Fabric Switch with the appropriate interconnect bay according to
your enclosure’s specific configuration.
5.
Push firmly into the interconnect bay. See
Table 6
Release mechanism components
Item
Description
1
Installation handle in latched position
2 Handle
latch
3
Installation handle released
scale: 2/3" = 1"
17
18
19
20
!
EXT 7
EXT 6
EXT5
1
2
3
1
81736
