TCP and UDP port numbers used by LO100
The following table lists the TCP and UDP port numbers used by the various LO100
network-accessible features. You can use this information to configure networking infrastructure or
security settings.
Embedded by default Support Protocol Port number
Yes Secure Shell connections SSH 22
Yes Command line interface,
Remote text console Telnet 23
Yes Firmware upgrade TFTP 69
Yes Firmware upgrade HTTP 80
Yes Web-based user interface
and LO100
Virtual KVM
SNMP trap 162
Yes Secure access to the
web-based user
interfaceVirtual KVM HTTPS 443
Yes IPMI-over-LAN connections IPMI RMCP+ 623
Yes IPMI-over-LAN connections Secure IPMI RMCP+ 664
Yes Storage Storage 5901
Updating the firmware
To update the LO100 firmware, use the ROMPaq utility. Downloads for the ROMPaq utility are
available on the HP website at
http://www.hp.com/support . For more information about using
the ROMPaq utility, see the HP website at http://www.hp.com/servers/manage .
NOTE: LO100 does not support ROMPAQ flashing from virtual media.
After the ROMPaq utility flashes the selected device, cycle power manually to reboot the operating
system.
Remotely updating the firmware
Use the load command to remotely update the LO100 firmware. The firmware file must be an
uncompressed firmware image file created using the DOS ROMPAQ utility found on the Lights-Out
100 Firmware Upgrade Diskette Utility, which is available for download from the HP website at
http://www.hp.com/servers/lights-out .
To create an uncompressed image file, enter the following command at the DOS prompt:
ROMPAQ /D
where <infile> is the ROMPAQ firmware image file and <outfile> is the file name for the
uncompressed binary image file. For example:
ROMPAQ /D cpqq0801.D14 ldrImage.bin
ROMPAQ Firmware Upgrade Utility, Version 5.02 (R)
Copyright (c) Hewlett-Packard Corporation, 1994-2006
Input file: CPQQ0801.D14
Output file: LDRIMAGE.BIN
The load command is used to retrieve a binary image from a specific source location (specified
as a URL) and place it at the specified target address.
14 Configuration
