B Technical specifications
NOTE: All performance specifications are provided by the component manufacturers. Performance
specifications represent the highest specification of all HP's component manufacturers' typical level
specifications for performance; actual performance might vary either higher or lower.
HP Digital Signage Display
Table B-1 Specifications
HP LD4730 HP LD4730G
Display Size 120.24 cm (47.3 in) 120.64 cm (47.5 in)
Type TFT LCD panel with LED
backlight TFT LCD panel with LED
backlight
Viewable image size 119.3 cm (46.9 in) 119.7 cm (47.1 in)
Pixel pitch 0.76125 x 0.76125 mm
(0.0299 x 0.0299 in) 0.76125 x 0.76125 mm
(0.0299 x 0.0299 in)
Weight — maximum Without stand and
speaker 23.82 kg (52.52 lbs) 29.02 k (63.98 lbs)
With speaker 24.58 kg (54.19 lbs) 29.78 kg (65.65 lbs)
With stand 25.24 kg (55.64 lbs) 30.44 kg (67.11 lbs)
With stand and
speaker 26.02 kg (57.36 lbs) 31.22 kg (68.832 lbs)
Dimensions
(W x H x D)
Without stand and
speaker 104.68 x 59.16 x 9 cm (41.21
x 23.29 x 3.54 in) 105.09 x 59.57 x 9.4 cm
(41.37 x 23.45 x 3.7 in)
With stand 104.68 x 66.47 x 29.83 cm
(41.21 x 26.16 x 11.7 in) 105.09 x 66.88 x 29.83 cm
(41.37 x 26.33 x 11.7 in)
With Frame 106.05 x 60.53 x 9.55 cm
(41.75 x 23.83 x 3.75 in)
Bezel width Top and left sides in
landscape orientation
Bottom and right sides
in landscape
orientation
3.9 mm
2.4
3.9 mm
2.4
Power Rated voltage AC 100-240 V~50/60 Hz 2 A
Japan: AC 100 V~50/60 Hz
2 A
AC 100-240 V~50/60 Hz 2 A
Japan: AC 100 V~50/60 Hz
2 A
Power consumption On mode 250 watts 250 watts
Sleep mode .5 watts .5 watts
Aspect ratio 16:9 16:9
Resolution —
maximum 1920 x 1080 @ 60 Hz 1920 x 1080 @ 60 Hz
ENWW HP Digital Signage Display 55
