Icon Menu Function description
Color Calibration Launch the color calibration process.
Tile Mode Set or change the tiling options when this display is one of an array.
The following table lists the On-Screen Display (OSD) menu selections and their functional
descriptions. Not all options apply to all types of input. For example, clock adjustment is only
applicable to VGA input.
Level 1 Menu Level 2 Menu Level 3 Menu Description
Picture Picture Mode The three preset modes set the picture submenu options for
the following:
● Vivid — For standard video.
● Standard — For viewing images.
● Cinema — For movies.
● If you prefer to set the picture submenu options yourself,
you will automatically switch to Expert 1
The default setting is Standard.
Contrast Increase or decrease the difference between the light and dark
colors.
Adjustable scale, 0 – 100 with 100 being high contrast.
The default setting is 50.
Brightness 0 — 100 scales adjusts the brightness of the screen.
The default setting is 50.
Sharpness 0 — 10 scale makes the image crisper or softer. When you
change this setting, the change will show immediately so that
you can judge where you want it to be.
The default setting is 5.
Backlight Controls the brightness of the backlight, 0 – 100.
The default setting is 90.
Dynamic
Contrast On — Allows the display to adjust the backlight for better
contrast, depending on the image.
Off — Does not allow the display to change the backlight level
depending on the image.
The default setting is OFF.
