Level 1 Menu Level 2 Menu Level 3 Menu Description
DHCP Dynamic Host Configuration Protocol
Enable — Allows the network host computer to assign an IP
Address to the display when it comes on line.
Disable — Allows you to assign a permanent IP Address and
Subnet Mask.
The default setting is Enable.
IP Address The Internet Protocol address needed for a network
connection.
The default is 192.168.0.2
Subnet Mask A number specific to your network used in conjunction with the
IP address.
The default is 255.255.255.0
VOE Setup These fields are recognized by the Video Over Ethernet
software.
Display Name — Give this display a name up to 32
alphanumeric characters long for reference through the VOE
software.
Display Location — Identify this display's physical location in
a way meaningful to you. Use up to 32 alphanumeric
characters.
Product Name — Automatically shows either LD4730 or
LD4730G.
Player Name — The computer name of a computer/media
player running VOE software whose output is to be played on
this display. You can enter such a name. The VOE software
will enter a name when it assigns a video source to this
display.
Option 2 Language Selects the language in which the OSD menu is displayed.
The default setting is English.
OSD Mode Set the OSD orientation to match the display's orientation,
portrait or landscape.
The default setting is landscape.
TIME Clock Set the current date and time so that scheduled events
happen at the correct time.
Year: 2000 – 2099
Month: 1 – 12
Day: 1 – 31
Hour: 0 – 23
Minute: 0 – 59
Daylight saving time: ON/OFF
The default setting is Off.
40 Chapter 4 Operating the display ENWW
