11. If you want to connect this display to another in an IR daisy chain, plug the included IR Daisy
Chain cable into the IR-OUT jack (13). The free end will plug into the IR-IN of the next display in
the chain.
Figure 3-29 IR-OUT connection
Connecting multiple displays to one player
Multiple displays may be connected to a single media player/computer two different ways, using
Video Over Ethernet or using Tile Mode with VGA or DisplayPort video inputs.
Connecting multiple displays with Video Over Ethernet (VOE)
To connect multiple displays to a single media player/computer, each display must be connected to
the same network as the media player/computer. The input source of each display must be set to
VOE. With VOE, displays are connected to media players/computer by establishing an Association
between the media player/computer and one or more displays on the network with the VOE software
that runs in the media player/computer. Up to 12 displays may be associated with a single media
player/computer (See the
VOE Users Guide for more detail). When multiple displays are associated
with a single media player/computer, the displays may be mirrored (a single desktop image displays
on all the displays simultaneously).
Figure 3-30 Mirrored displays
The image may be extended across all the displays simultaneously using the View Span “Display
Resolution” dialog box.
22 Chapter 3 Setting up the display ENWW
