HP LD4730 47-inch Micro-Bezel Video Wall Display User Manual
Page 29
Figure 3-27
Connecting the Ethernet cable
1
2
3
10.
If you want to use the external IR sensor, plug it into the IR-IN jack (12). The external sensor
makes using the remote easier, especially with displays mounted in a video wall.
Figure 3-28
Infrared sensor connection
Place the IR sensor facing where you want the remote to be.
ENWW
Connecting cables
21
