Accessing the Device
Page 3-6
Menu Components
The menus on the AsantéHub 1016-IQ Device Page provide access to
the different management options supported by the Personality Module.
Tables
Some menus contain tables with information that is configurable
directly on-screen from your Web browser while others contain informa-
tion that is read-only. The following tables describe how to recognize
configurable and read-only information.
Configurable Information
Read-only Information
Table Columns
Some table columns can be resized to fit the width of your screen. To
resize a table column, place the mouse pointer on a column title’s left or
right side (until a double arrow appears) and drag the column to the left
or to the right, as desired.
Buttons
Some menus contain buttons which allow you to edit/and or update the
page.
Table field Action
Drop-down menu Select from an available option.
White-colored fields Type information.
Table field Action
Green- or gray-colored fields None; field cannot be edited.
Button Action
Apply Applies any changes made to the device.
Refresh Updates the table with the latest information.
Modify Modifies a selected entry.
Add Adds an entry into the table.
