AudioCodes MEDIAPACK VERSION 6.2 - Manual (Page 72)

SIP Release Notes 72 Document #: LTRT-26901
CPE SIP Products
1.7 Data-Router New Features
The device supports the following new data-router features:
1. Dual WAN over T1 Interface Ports:
Product
MP-11x MP-124
Mediant 600 Mediant 1000
Mediant 800 MSBG Mediant 1000 MSBG
Mediant 2000
Mediant 3000/TP-6310 Mediant 3000 HA/TP-6310
Mediant 3000/TP-8410 Mediant 3000 HA/TP-8410
Management Protocol
Web INI SNMP EMS CLI
The device now supports two physical WAN T1 links, thereby allowing a bandwidth of
up to 3 Mbps. The T1 WAN connection is through a Dual T1 line interface (according
to ANSI T1.403-1999). The device uses its Dual T1 WAN Data Service Unit/Channel
Service Unit (DSU/CSU) port interface to transmit and receive data using IP over
Point-to-Point Protocol (PPP) framing (up to two separate links), IP over High-Level
Data Link Control (HDLC) framing (up to two separate links), or bundling both physical
links into a single logical link using IP over Multilink Point-to-Point Protocol (MLP)
framing (RFC 1717).
2. BER Test for T1 WAN Interface:
Product
MP-11x MP-124
Mediant 600 Mediant 1000
Mediant 800 MSBG Mediant 1000 MSBG
Mediant 2000
Mediant 3000/TP-6310 Mediant 3000 HA/TP-6310
Mediant 3000/TP-8410 Mediant 3000 HA/TP-8410
Management Protocol
Web INI SNMP EMS CLI
The device now supports bit error rate (BER) testing on the T1 WAN interface for the
far-end transmission link. The BER Test is done by generating and detecting both
pseudorandom and repeating bit patterns. The test is enabled using the ber-test
CLI command.
