SIP Release Notes 2. Supported Features
2.5.2 Mediant 600 and Mediant 1000
The device supports the following DSP firmware templates:
Notes:
• Installation and use of vocoders is subject to obtaining the appropriate
license and to royalty payments.
• The number of channels refers to the device's maximum channel
capacity.
• The maximum number of channels on any form of analog, digital and
MPM modules assembly is 120.
• Assembly of the MPM module in Slot 6 enables DSP conferencing
capabilities.
• For other DSP template configurations, please contact AudioCodes.
Table 2-13: DSP Firmware Templates for Mediant 600 and Mediant 1000 Analog (FXS/FXO)
Interfaces
DSP Template
0, 1, 2, 4, 5 10, 11, 12, 14,15
Number of Channels
Default Settings 4 3
With SRTP 3 3
Voice Coder
G.711 A/Mu-law PCM Yes Yes
G.726 ADPCM Yes Yes
G.727 ADPCM Yes Yes
G.723.1 Yes Yes
G.729 A, B Yes Yes
EG.711 Yes -
G.722 - Yes
