SIP Release Notes 30 Document #: LTRT-26901
CPE SIP Products
7. Increase in Characters for Endpoint Phone Number:
Product
MP-11x MP-124
Mediant 600 Mediant 1000
Mediant 800 MSBG Mediant 1000 MSBG
Mediant 2000
Mediant 3000/TP-6310 Mediant 3000 HA/TP-6310
Mediant 3000/TP-8410 Mediant 3000 HA/TP-8410
Management Protocol
Web INI SNMP EMS CLI
The maximum number of characters that can be defined for an endpoint phone
number has been increased from 25 to 50. The phone numbers are configured using
the TrunkGroup parameter (Endpoint Phone Number table for MP-1xx and Trunk
Group table for digital devices).
8. Forwarding IP-to-Tel Calls to Alternative SIP Request-URI upon Busy Trunk:
Product
MP-11x MP-124
Mediant 600 Mediant 1000
Mediant 800 MSBG Mediant 1000 MSBG
Mediant 2000
Mediant 3000/TP-6310 Mediant 3000 HA/TP-6310
Mediant 3000/TP-8410 Mediant 3000 HA/TP-8410
Management Protocol
Web INI SNMP EMS CLI
This feature enhances the existing Forward On Busy Trunk Destination feature
(configured using the ForwardOnBusyTrunkDest parameter), which until now
supported the configuration of only an IP address for call redirection. This feature now
allows the redirect destination to be configured as a SIP Request-URI user name and
host part (i.e., user@host), or host name (i.e., IP address). For example, the below
configuration forwards IP-to-Tel calls to destination user “112” at host IP address
10.13.4.12, port 5060, using transport protocol TCP, if Trunk Group ID 2 is
unavailable:
ForwardOnBusyTrunkDest 1 = 2, [email protected]:5060;transport=tcp;
When configured with user@host, the original destination number is replaced by the
user part.
