SIP Release Notes 1. What's New in Release 6.2
31. Additional VXML Script Attributes for Invoking VXML Scripts:
Product
MP-11x MP-124
Mediant 600 Mediant 1000
Mediant 800 MSBG Mediant 1000 MSBG
Mediant 2000
Mediant 3000/TP-6310 Mediant 3000 HA/TP-6310
Mediant 3000/TP-8410 Mediant 3000 HA/TP-8410
Management Protocol
Web INI SNMP EMS CLI
This feature provides support for the following additional VXML session variables and
events:
• session.connection.local.uri
• session.connection.remote.uri
• session.connection.protocol.name
• session.connection.protocol.version (version is ‘2’ instead of ‘2.0’)
• session.connection.redirect (redirect reason and screening information contains
‘_’ instead of whitespace between words)
• session.connection.aai
32. Activating VXML Script on Receipt of Regular INVITE:
Applicable Product
MP-11x MP-124
Mediant 600 Mediant 1000
Mediant 800 MSBG Mediant 1000 MSBG
Mediant 2000
Mediant 3000/TP-6310 Mediant 3000 HA/TP-6310
Mediant 3000/TP-8410 Mediant 3000 HA/TP-8410
Management Protocol
Web INI SNMP EMS CLI
This feature provides support for activating a Voice XML (VXML) script using the
VXMLID parameter in the Request-URI user part only, upon receipt of a regular
INVITE message. For example:
Request-URI = http://mydomain.com/myscript.cgi@host;
Up till now, VXML was invoked on the receipt of SIP Request-URIs such as:
@host;voicexml= http://...
This feature is supported for IP-to-Tel and Tel-to-IP calls. For specified dialed phone
numbers, the user part can be manipulated by adding a VXML script path. For
example, upon receipt of the INVITE request, INVITE sip:100@myhost the device
can be configured to manipulate (using the IP to Tel Manipulation table) the Request-
URI user part to voicexml=http://myhost.com/script.cgi@myhost.
