ADSP-2181/ADSP-2183
REV. 0 –33–
OUTLINE DIMENSIONS
128-Lead Metric Thin Plastic Quad Flatpack (TQFP)
65
64
102
103
1
128
39
38
E
3
E
1
E
B e
D 3
D
1
D
TOP VIEW
(PINS DOWN)
SEATING
PLANE
L
A
D
A 1
A
2
MILLIMETERS INCHES
SYMBOL MIN TYP MAX MIN TYP MAX
A 1.60 0.063
A
1
0.05 0.15 0.002 0.006
A
2
1.30 1.40 1.50 0.051 0.055 0.059
D 15.75 16.00 16.25 0.620 0.630 0.640
D
1
13.90 14.00 14.10 0.547 0.551 0.555
D
3
12.50 12.58 0.492 0.495
E 21.75 22.00 22.25 0.856 0.866 0.876
E
1
19.90 20.00 20.10 0.783 0.787 0.792
E
3
18.50 18.58 0.728 0.731
L 0.45 0.60 0.75 0.018 0.024 0.030
e 0.42 0.50 0.58 0.017 0.019 0.023
B 0.17 0.22 0.27 0.007 0.009 0.011
0.10 0.004 D
