Control Panel
GL2 Settings
Setting Item Description, Instructions
GL2 Replot Print the last printed job (still stored in the printer memory) again.
GL2 BufferClear Delete the last job printed using HP-GL/2, still stored in the printer memory.
Color Mode Choose the color mode.
Print Quality Choose the print quality.
Input Resolution Choose the printer input resolution, 600dpi or 300dpi.
Media Source Choose the media source forHP-GL/2 printing.
Conserve Paper Conserves paper when printing.
Line Cap Choose the shape of the end point, determined by Software or Rounded.
• If you choose Software
Operation is determined by the application. If nothing is specied by the application,
the result is as shown in the gure.
• If you choose Rounded
Smoothing Choose whether to print arcs as smooth curved lines or as multiple connected line
segments.
• If you choose Software
Operation is determined by the application. If nothing is specied by the application,
the result is as shown in the gure.
Note: By default, this is a 72-sided gure
• If you choose Smooth
Line Width Choose the width for printing lines if no width is specied in the data. Dots in the line
width are 300 dpi each.
ThickenFineLines Select On to print ne lines more distinctly.
AdjustFaintLines If ne lines are printed in colors that do not match the colors of other shapes, selecting
Off may help produce the expected results. However, lines in some colors may
appear broken.
